Pressure Transmitter 7MF0440-3GL02-5AM2-Z A03+C20+E00+E80+H02+Y01+Y02+Y15

SITRANS P420 Pressure transmitter Differential pressure and flow PN160 HART (4...20 mA) Measuring cell filling: Inert liquid Maximum measuring span: 250 mbar (100.5 inH²O) Oval flange, fastening thread: 7/16-20 UNF (IEC 61518) Diaphragm: Stainless steel 316L/1.4404, measuring cell: Stainless steel 316L/1.4404; Sensor Differential pressure: process flange: Stainless steel 316/1.4408 Housing made of stainless steel precision casting CF3M/1.4409 (similar to 316L) Dual chamber device no Ex 2 x 1/2-14 NPT With display (lid with glass window) Cable gland attached, stainless steel 316L/1.4404 Functional Safety (IEC 61508) - SIL2/3; Electrical equipment for furnaces and ancillary equipment (EN 50156-2) General approval without Ex approval: World (CE, RCM) except: EAC, FM, CSA, KCC Oxygen version (inert liquid max. 100 bar (1450 psi) at 60 °C (140 °F); measuring cell cleaning free of grease according to cleanliness level 2, DIN 25410; transmitter package with protective film) Mounting bracket, stainless steel 1.4301/304 Measuring range setting: Lower range value (max. 5 characters). Upper range value (max. 5 characters). Unit (mbar. bar. kPa. MPa. psi. ...) Example: -0.5 ... 10.5 psi Characteristic curve square root: (VSLN2. MSLN2). example: VSLN2 Location designation (Tag) (stainless steel plate. device parameters. max. 32 characters) TAG plate without marking please order via option D40
