Pressure Transmitter 7MF0340-1ML01-5AF2-Z A00+B13+C12+C14+E01+H01+U04+Y01+Y02+Y15+Y21

SITRANS P320 Pressure transmitter Differential pressure and flow PN160 HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 1600 mbar (643 inH²O) Oval flange, fastening thread: 7/16-20 UNF (IEC 61518) Process connection: Stainless steel 316L/1.4404, Seal diaphragms: Stainless steel 316L/1.4404, Sensor differential pressure: Process flange: Stainless steel 316/1.4408 Die-cast aluminum housing Dual chamber device no Ex 2 x M20 x 1.5 With display (lid with glass window) Cable gland and sealing plug attached, plastic Labeling type plate Spanish - bar Inspection certificate (EN 10204-3.1) - material of pressure-containing and wetted parts Factory certificate (EN 10204-2.2) - wetted parts General approval without Ex approval: World (CE, UKCA, RCM, CSA, EAC, FM, KC) Mounting bracket, electrogalvanised steel with mounted manifold (5-fold) 7MF9411-5CA, PTFE sealings, stainless steel screws and pressure test, certified with a factory certificate (EN 10204-2.2) Measuring range setting: Lower range value (max. 5 characters), Upper range value (max. 5 characters), Unit (mbar, bar, kPa, MPa, psi, ...) Example: -0.5 ... 10.5 psi (stainless steel plate) Characteristic curve square root: (VSLN2. MSLN2). example: VSLN2 Location designation (Tag) (stainless steel plate. device parameters. max. 32 characters) TAG plate without marking please order via option D40 Display: (pressure. % of range). pressure reference (none. absolute. gauge). example: pressure gauge
