Transmitter 7ME2610-2BJ00-0AF2-Z A02+E00+Y40+Y41+Y42+Y43+Y44+Y45

SITRANS FX330 Vortex flowmeter, flanged design, diameter DN 15 to DN 300 (1/2" to 12"). Suitable for volume flow, pressure and temperature measurement of liquids, gases and steam, for applications like heat metering of steam and hot water, consumption of industrial gases, process controls of conductive and non-conductive liquids, safety-related measurement in SIL applications (SIL2). Standard version (without SIL approval) DN25 (1") - Sensor size DN25 (1") with connection size DN25 (1") ANSI B16.5 RF, class 150 Compact design without cable Aluminium HART Communication Without Ex approval Integrated pressure sensor 10 bar Gasket material pressure sensor FPM (Viton) Density compensation for steam + Heat meter for saturated and superheated steam M20x1.5 cable glands (3 cable entries) in plastic, grey General approval: World (CE) except: EAC, KCC, UKCA, CRN Medium: Specify medium (Steam, gas, liquid or customized) Temperature: Specify operating temperature and unit Pressure: Specify operating pressure and unit Density: Specify density and units Viscosity: Specify viscosity and units Flow rate: Specify max. flow rate and unit
